Circular flat and bellow Maxigrip Suction cups
These Suction cups have been created as an alternative to the ordinary cups used in the robot-automotive field and they offer an excellent solution to gripping and handling problems that could arise on vacuum-driven handlers in every industry sector. They can be both flat and bellow-type, round and oval and equipped with support. The extremely flexible outside lip, can be associated with the typical features of the bellow cups, allow them to adapt themselves on flat, concave and convex surfaces with no risk of deforming or breaking even the thinnest objects to be handled. The innovative design of the inside of the cups, which facilitates the drainage of oil and water, ensures a high friction coefficient with the gripping surface and, in particular, a unique grip on oil-covered metal sheets or wet glass or marble sheets. This particular feature guarantees a firm grip and, therefore, an accurate placemet of the load to be handled. The MAXIGRIP standard vacuum cups are made with our exclusive BENZ compound:
- Hardness 60÷75°Sh.
- Working temperature between -40 and +170 °C
- Excellent resistance to abrasion, water and to oils containing chlorine.
Their galvanised steel support is vulcanised onto the cup. A wide range of accessories, such as adapters, couplers and articulated joints, allows them to be installed on any vacuum-driven handler. Because of their universality of use, these cups can also be provided in the special compounds shown on top.
Product codes: VRP40 VRP50 VRP60 VRP80 VRP100 VRP125 VRS40 VRS50 VRS60 VRS80 VRS100 VRS125
